8-Port Combo KVM Switch PLANET KVM-210-08

Mã sản phẩm: PLANET KVM-210-08 Lượt xem: 496

Mô tả sản phẩm:

1U rack-mount size and desktop design. Auto scan mode for monitoring computers

Thương hiệu

PLANET

Mô tả chi tiết Đánh giá Bình luận

Mô tả chi tiết

8-Port Combo KVM Switch PLANET KVM-210-08

Hardware

- 1U rack-mount size and desktop design.

- Standalone machine controls up to 8 sets of computers.

- Up to 2 levels can be cascaded and up to 64 computers can be controlled.

- Front panel status LEDs give a clear indication of the active computers.

- Supports a high resolution of up to 2048 x 1536 and 350MHz of bandwidth.

Security

- Two-layer password security protection.

Management

- Auto scan mode for monitoring computers.

- Requires no additional software or hardware.

- Computer selection via Port Select Button, Hotkey and On Screen Display (OSD).

- Hot pluggable: Add or remove computers without having to power down the switch.

- QVS (Quick View Setting): Quickly select your computer by naming or SN number.

Compatibility

- Multiplatform support -- Windows, Linux and Sun.

- Supports Microsoft Intellimouse, Logitech Net Mouse and all other third party’s PS/2 mice.

Specifications

Hardware
Number of Ports	8
Maximum	64 by cascading (KVM-210-08 x 8)
PC Ports	Keyboard: PS/2 female + USB Type A female
	Mouse: PS/2 female + USB Type A female
	Video: 8 x HDB-15 female
Console Ports	Keyboard: PS/2 female + USB Type A female
	Mouse: PS/2 female + USB Type A female
	Video: 1 x HDB-15 female
LED	On Line: 8
LED	Selected: 8
Button	Reset: 1
Button	Select: 8
Video Resolution	2048 x 1536
Housing	Metal
Dimensions (W x D x H)	432 x 155 x 44 mm
Weight	2.22kg
Power Requirement	9V DC, 1A
Installation	1U rack-mountable, desktop
Management
PC Selection	Port select button Hotkeys on keyboard OSD (on screen display)
Scan Interval	5~60 seconds
Security	User password and super password
Environment & Certification
Operating Temperature	-10 ~ 50 degrees C
Operating Humidity	0 ~ 90%
Regulatory	CE, FCC
